Multilayer PCB Board Prototype Printed Circuit Board with Impedance Control
Abis Circuits Co., Ltd is a professional PCB manufacturer in China, Shenzhen. With 14 years+ development, we could make the PCB from 1L to 20L, with monthly production capability of 60,000 square meters. Abis Circuits is providing high-quality bare PCB and PCB assembly service, including components sourcing, function test, conformal coating, and complete assembly for clients all over the world, Our main market is Europe, north USA, Australia, South America, and Asia.
● Founded in 2006, over 1100 skilled workers in two shifts
● Certified by UL, ISO14001, RoHS, all our products can meet the IPC II&III
● OEM/ODM orders accepted, with a monthly capacity of 60000㎡on two bases.
● Our products include single, double, multi, high frequency, aluminum base, copper base, FR-4, and other high precision circuit board.
● Application Industries: Lighting, Telecommunication, Computer, Industrial Control, Consumer Electronics, Automotive
Factory: Operation plant space: (I) 10000 Square meters (II) 60000 Square meters
Employees: (I) 300 Man Powers (II) 900 Man Powers
Eng. Technical: (I) 20 QA QC Engineers (II) 60 QA, QC Engineers
Capacity
| Raw material | FR-4, Metal core, Cu base, Polymide, Ceramic, Rogers, etc. |
| Layer | 1 Layer-20 Layer |
| Min.Line width/space | 3mil/ 3mil (0.075mm/0.075mm) |
| Min. hole size | 0.1mm (drilling hole) |
| Max. Board size | 1200mm*600mm |
| Finished board thickness | 0.2mm-6.0mm |
| Cooper foil thickness | 18um- 280um (0.5oz-8oz) |
| NPTH Hole Tolerance | +/- 0.075mm |
| PTH hole Tolerance | +/-0.05mm |
| Outline tolerance | +/-0.13mm |
| Surface finished | Lead-Free HASL, immersion gold(ENIG), Immersion silver, OSP, gold plating, gold finger, Carbon INK |
| Production capability | 60,000 s.q.m/ month |
Lead Time
| Category | Q/T Lead time | Standard Lead Time | Mass Production |
| |
| 2 Layers | 24hrs | 3-4 working days | 8-15 working days |
| |
| 4 Layers | 48hrs | 3-5 working days | 10-15 working days |
| |
| 6 Layers | 72hrs | 3-6 working days | 10-15 working days |
| |
| 8 Layers | 96hrs | 3-7 working days | 14-18 working days |
| |
| 10 Layers | 120hrs | 3-8 working days | 14-18 working days |
| |
| 12 Layers | 120hrs | 3-9 working days | 20-26 working days |
| |
| 14 Layers | 144hrs | 3-10 working days | 20-26 working days |
| |
| 16-20 Layers | Depends on the specific requirements |
| |
| 20+ Layers | Depends on the specific requirements |
FAQ:
Q1: How can I get a quotation:
. Please send gerber file with format: .PCB / .P-CAD / .DXP / .Gerber
Q2: Can you manufacture my PCBs from a picture file?
. Could you please provide a sample?
Q3: Do you have PCB in stock?
. Most of our PCB board are customized, which according to Gerber file.
. ABIS has samples in stock that could be sent to you for quality checking always.
Q4: What board manufacturer do you use for FR4?
. Main Suppliers(FR4): Kingboard (Hong Kong), NanYa (Taiwan), and Shengyi (China).
Q5: Will my PCB files be checked?
. Checked within 12 hours. Once Engineer's question and working file be approved, production will start.
Q6: What do you require in order to produce an assembly quotation?
. Bill of materials (BOM) detailing:
a), manufacturers parts numbers,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
d), Quantity
