FR4 ENIG Flexible Rigid PCB Board Mobile Charger PCBA Motherboard TS16949

  • 1
  • 2

Brand Name : ABIS

Model Number : H-PCB2

Certification : ISO14001, ISO9001, UL, cUL, TS16949

Place of Origin : China

MOQ : 1

Price : Customized

Payment Terms : T/T, Western Union, paypal ect.

Supply Ability : 60,000sqm per month

Delivery Time : 1-15 working days

Packaging Details : vacuum package

Base Material : FR4,PI,FR-4/aluminum/ceramic

Copper : 0.5oz/1oz/ 2oz/3oz

PCB Thickness : 0.2mm-6.0mm

Surface finishing : HASL,OSP,ENIG

Application : Consumer Electronics

Legend Color : Black Yellow Green Red White

Min. line width : 0.075mm(3mil)

Product name : PCB Board Assembly

Layer : 1-20 layers

Usage : OEM Electronics

Mini Holes : 0.10mm

Solder Mask Color : Red / Blue / Green / Black / White / Customize

Contact Now

FR4 ENIG Flexible Rigid PCB Board Mobile Charger PCBA Motherboard TS16949

FR4 ENIG Flexible Rigid PCB Board Mobile Charger PCBA Motherboard TS16949

Technical capabilities:

Item Production Capacity
Layer Counts 1-20 layers
Material FR-4,Cu base,High TG FR-4,PTFE,Rogers,TEFLON etc.
Board thickness 0.20mm-8.00mm
Maximum Size 600mmX1200mm
Board Outline Tolerance +0.10mm
Thickness Tolerance(t≥0.8mm) ±8%
Thickness Tolerance(t<0.8mm) ±10%
Insulation Layer Thickness 0.075mm--5.00mm
Minimum Line 0.075mm
Minimum Space 0.075mm
Out Layer Copper Thickness 18um--350um
Inner Layer Copper Thickness 17um--175um
Drilling Hole(Mechanical) 0.15mm--6.35mm
Finish Hole(Mechanical) 0.10mm-6.30mm
Diameter Tolerance(Mechanical) 0.05mm
Registration(Mechanical) 0.075mm
Aspect Ratio 16:1
Solder Mask Type LPI
SMT Mini.Solder Mask Width 0.075mm
Mini. Solder Mask Clearance 0.05mm
Plug Hole Diameter 0.25mm--0.60mm
Impedance control Tolerance ±10%
Surface finish/treatment HASL,ENIG,Chem,Tin,Flash Gold, OSP, Gold Finger

Related Products:

FR4 ENIG Flexible Rigid PCB Board Mobile Charger PCBA Motherboard TS16949

Packaging & Delivery

ABIS CIRCUITS Company is not only trying to give customers a good product, but also pay attention to offering a complete and safe package. Also, we prepare some personalized services for all the orders.

-Common packaging:

  • PCB: Sealed bag, Anti-static bags, Suitable carton.
  • PCBA: Antistatic foam bags, Anti-static bags, Suitable carton.
  • Customized Packaging: The carton outside will be printed the name of the customer address, mark, the customer needs to specify the destination and other information.

6.By Paypal,T/T,West Union,etc.

Company Profile:

ABIS CIRCUITS CO., LTD

FR4 ENIG Flexible Rigid PCB Board Mobile Charger PCBA Motherboard TS16949

FR4 ENIG Flexible Rigid PCB Board Mobile Charger PCBA Motherboard TS16949

FR4 ENIG Flexible Rigid PCB Board Mobile Charger PCBA Motherboard TS16949

Workshop:

FR4 ENIG Flexible Rigid PCB Board Mobile Charger PCBA Motherboard TS16949

Exhibition show:

FR4 ENIG Flexible Rigid PCB Board Mobile Charger PCBA Motherboard TS16949

FAQ:

Q1:Are you a factory or trade company?
A: Abis is a PCB/FPC/PCBA manufacturer/factory. We pecialize in PCB/PCBA Board for 12 years.

Q2:Is my PCB file safe if I send it to you for manufacturing?
A: We respect customer's design authority and will never manufacture PCB for someone else without your permission. NDA is acceptable.

Q3:What is your testing policy and how you control the quality?
A: For sample, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by fixture, this will be more faster. Due to there's many steps to PCB production, we usually do inspection after every step.

Q4: What's your shipping way ?
A: 1. We have our own forwarder to ship goods by DHL, UPS, FEDEX, TNT,EMS.
2. If you have your own forwarder, we can cooperate with them.

Q5: What is your certificate?
A: ISO9001:2015, ISO14001: 2015, UL, SGS,RoHS report.
