Quick Turn Metering Multi Layer PCB Main Board with HASL Finishing
Abis Circuits Co. Ltd, established in 2006, Located in Shenzhen, our company has about 1100 workers and two PCB workshops with about 50000 square meters.
1. Single, Double side & Multi-layer PCB.
2. Buried/Blind Vias, Via in Pad, Counter Sink Hole, Screw Hole(Counterbore), Press-fit, Half Hole.
3. HASL lead-free, Immersion Gold/ Silver/Tin, OSP, Gold plating/finger, Peelable mask,
4. Printed Circuit Boards adhere to IPC Class 2 & 3 international PCB standard.
5. Quantities range from prototype to medium&big batch production.
6.100% E-Test.
Multiple Quality Assuring Procedures
* Visual Inspection
* Flying probe, fixture tool
* Impedance control
* Solder-ability detection
* Digital metallographic microscope
* AOI (Automated Optical Inspection
Monthly Capacity
| Monthly Capacity |
| Small volume and quick turn | Reached 12,000 sqm per month, 2000+ types quick turn PCB in 2018. |
| |
| High volume | Reached 60,000 sqm per month in 2018 |
| |
| 2019 plan | Reach 100,000 sqm and 3000+ types quick turn PCB per month |
Lead Time:
| Category | Q/T Lead time | Standard Lead Time | Mass Production |
| |
| 2 Layers | 24hrs | 3-4 working days | 8-15 working days |
| |
| 4 Layers | 48hrs | 3-5 working days | 10-15 working days |
| |
| 6 Layers | 72hrs | 3-6 working days | 10-15 working days |
| |
| 8 Layers | 96hrs | 3-7 working days | 14-18 working days |
| |
| 10 Layers | 120hrs | 3-8 working days | 14-18 working days |
| |
| 12 Layers | 120hrs | 3-9 working days | 20-26 working days |
| |
| 14 Layers | 144hrs | 3-10 working days | 20-26 working days |
| |
| 16-20 Layers | Depends on the specific requirements |
| |
| 20+ Layers | Depends on the specific requirements |
How to get a quote?
Please send gerber file with these format: .PCB / .P-CAD / .DXP / .CAD / .Gerber
a) Base material: FR4/ AL/ FPC/ CEM-1/ CEM-3/ 94v0/ Rogers
b) Board thickness: 1.6mm-3.2mm/ 0.2mm-1.2mm
c) Copper thickness: Hoz/ 1oz/ 2oz/ 3oz/ 4oz, ect
d) Surface treatment: HASL/ ENIG/ LF-HAL/ Immersion Tin/ Immersion Sin/ OSP
e) Color of solder mask and silkscreen: Green/White/Black/Red/Blue/Yellow
f) Quantity and board size
FAQ:
Q1: How can I get a quotation:
. Please send gerber file with format: .PCB / .P-CAD / .DXP / .Gerber
Q2: Can you manufacture my PCBs from a picture file?
. Could you please provide a sample?
Q3: Do you have PCB in stock?
. Most of our PCB board are customized, which according to Gerber file.
. ABIS has samples in stock that could be sent to you for quality checking always.
Q4: What board manufacturer do you use for FR4?
. Main Suppliers(FR4): Kingboard (Hong Kong), NanYa (Taiwan), and Shengyi (China).
Q5: Will my PCB files be checked?
. Checked within 12 hours. Once Engineer's question and working file be approved, production will start.
Q6: What do you require in order to produce an assembly quotation?
. Bill of materials (BOM) detailing:
a), manufacturers parts numbers,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
d), Quantity
